Self-aligning ball bearings have two structures: cylindrical bore and tapered bore, and the cage is made of steel plate, synthetic resin, etc. Its characteristic is that the outer ring raceway is spherical, with self-alignment, which can compensate the errors caused by misalignment and shaft deflection, but the relative inclination of the inner and outer rings should not exceed 3 degrees.
A self-aligning ball bearing is a bearing equipped with spherical balls between the inner ring of two raceways and the outer ring whose raceways are spherical. The curvature center of the outer ring raceway surface is consistent with the bearing center, so it has the same centering function as the self-aligning ball bearing. When the shaft or housing is deflected, it can be adjusted automatically without increasing the bearing burden. Spherical roller bearings can bear radial load and axial load in two directions. Large radial load capacity, suitable for heavy load and shock load. The inner diameter of the inner ring is a bearing with a tapered bore, which can be directly installed. Or use an adapter sleeve or a disassembly tube to install it on the cylindrical shaft. The cage uses a steel stamping cage, a polyamide forming cage and a copper alloy car cage.
Self-aligning ball bearings have two structures: cylindrical bore and tapered bore, and the cage is made of steel plate, synthetic resin, etc. Its characteristic is that the outer ring raceway is spherical and self-aligning, which can compensate the errors caused by the misalignment and shaft deflection caused by the self-aligning ball bearing, but the relative inclination of the inner and outer rings shall not exceed 3 degrees.
It can withstand large radial loads and at the same time can withstand certain axial loads. The outer ring raceway of this type of bearing is spherical, so it has self-aligning performance. When the shaft is bent or tilted and the center line of the inner ring and the center line of the outer ring are not more than 1°~2.5°, the bearing can still work.

Self-aligning ball bearings are suitable for bearing heavy loads and shock loads, precision instruments, low-noise motors, automobiles, motorcycles, metallurgy, rolling mills, mining, petroleum, papermaking, cement, sugar crushing and other industries and general machinery.
